Опора трубопровода Опоры трубопроводов SFS 5373
Вы можете купить металлоконструкции и строительные металлоизделия опора трубопровода Опоры трубопроводов SFS 5373. Добавьте товар в корзина для оформления заказа, выберите количество товара, базу отгрузки и адрес доставки.
Опора трубопровода Опоры трубопроводов SFS 5373
| d | DN | de | a | l | H | h | N | Заказать |
|---|---|---|---|---|---|---|---|---|
| 18,0 | 10,0 | 17,2 | 42,0 | 57,0 | 80,0 | 71,0 | 14600,0 | 1,20 |
| 22,0 | 15,0 | 21,3 | 56,0 | 75,0 | 84,0 | 73,0 | 14600,0 | 1,30 |
| 27,0 | 20,0 | 26,9 | 62,0 | 81,0 | 87,0 | 73,0 | 14600,0 | 1,30 |
| 34,0 | 25,0 | 33,7 | 69,0 | 88,0 | 90,0 | 73,0 | 14600,0 | 1,40 |
| 43,0 | 32,0 | 42,4 | 85,0 | 115,0 | 95,0 | 73,0 | 14600,0 | 1,50 |
| 49,0 | 40,0 | 48,3 | 89,0 | 119,0 | 98,0 | 73,0 | 14600,0 | 1,60 |
| 61,0 | 50,0 | 60,3 | 101,0 | 131,0 | 104,0 | 73,0 | 14600,0 | 2,80 |
| 77,0 | 65,0 | 76,1 | 126,0 | 158,0 | 113,0 | 74,0 | 20000,0 | 3,20 |
| 89,0 | 80,0 | 88,9 | 139,0 | 171,0 | 119,0 | 74,0 | 20000,0 | 3,30 |
| 115,0 | 100,0 | 114,2 | 174,0 | 218,0 | 134,0 | 76,0 | 33000,0 | 5,10 |
| 140,0 | 125,0 | 139,7 | 200,0 | 244,0 | 146,0 | 76,0 | 33333,0 | 5,50 |
| 169,0 | 150,0 | 168,3 | 229,0 | 273,0 | 161,0 | 76,0 | 33500,0 | 6,10 |
